Chevrolet Impala IX (2006-2016) heated heated oxygen oxygen sensor sensor Wiring diagram
This page shows the only wiring diagram for the component.heated heated oxygen oxygen sensor sensor, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heated heated oxygen oxygen sensor sensor (1 of 1)
A/C COMPRESSOR RELAY
BANK 1 BANK 2 SENSOR 1 SENSOR 1
BANK 1 BANK 2 SENSOR 2 SENSOR 2
BLK WIRE
ECM FUSE
EMISSIONS 1 FUSE
EMISSIONS 2 FUSE
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE (ECM)
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID VALVE
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FROM A/C CMPRSR RELAY (DIAGRAM 3 OF 4)
FROM IGN 2 FUSE (DIAGRAM 4 OF 4)
FUEL COMPOSITION SENSOR
FUEL PUMP RELAY
HEATED HEATED OXYGEN OXYGEN SENSOR SENSOR
HORN PCB RELAY
IGN 1 FUSE
IGN 2 FUSE
IGNITION COIL
IGNITION COIL 2, CAMSHAFT SENSORS)
IGNITION IGNITION COIL COIL
MULTI-FUNCTION INTAKE AIR SENSOR
PARK LP PCB RELAY
PNK PNK WIRE
PNK WIRE
PWR/TRN RELAY
STRTR RELAY
TO EMISSIONS 1 FUSE (DIAGRAM 4 OF 4)
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
VACUUM PUMP RELAY
WHT WIRE
WS WASH PCB RELAY
YEL WIRE
Go to component: -> Power distribution circuit (4 of 4) -> HEATED HEATED OXYGEN OXYGEN SENSOR SENSOR
