Chevrolet Impala IX (2006-2016) (forward lamp harness, 31.3 cm rear of Wiring diagram
This page shows the only wiring diagram for the component.(forward lamp harness, 31.3 cm rear of, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (forward lamp harness, 31.3 cm rear of (1 of 1)
BACKUP LAMPS CIRCUIT
BLK WIRE
BRN/LT GRN WIRE
CENTER HIGH MOUNTED STOP LAMP
DK BLU WIRE
DK BLU/WHT WIRE
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR LAMP ASSEMBLY
GRN WIRE
GROUND DISTRIBUTION
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
HEADLIGHTS SYSTEM LEFT TAIL LAMP
LEFT BACKUP LAMP LEFT TAIL/ STOP,
LEFT FRONT PARK LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT LICENSE PLATE LAMP
LEFT PARK/ TURN SIGNAL LAMP
LEFT PARK/DAYTIME (LUGGAGE COMPT, RUNNING LAMP LEFT WHEEL WELL) (IF EQUIPPED)
LEFT REAR SIDE MARKER LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TURN SIGNAL REPEATER LAMP
LOGIC
LT GRN/VIO WIRE
LT GRN/YEL WIRE
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR LAMP ASSEMBLY
RED WIRE
RIGHT LICENSE PLATE LAMP
RIGHT TURN SIGNAL REPEATER LAMP
SYSTEM
TURN SIGNAL LAMP
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ HID
W/O HID
YEL WIRE
YEL/DK BLU WIRE
Go to component: -> Exterior lamps circuit (2 of 3) -> (FORWARD LAMP HARNESS, 31.3 CM REAR OF
