Chevrolet Impala IX (2006-2016) (engine harness, 4 cm from branch to engine Wiring diagram
This page shows the only wiring diagram for the component.(engine harness, 4 cm from branch to engine, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (engine harness, 4 cm from branch to engine (1 of 1)
2.4L
2.5L
3.6L
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
AUTOMATIC TRANSMISSION ASSEMBLY CONTROL SOLENOID
AUXILIARY TRANSMISSION FLUID PUMP
BLK WIRE
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
CENTER CONSOLE COMPARTMENT LAMP
CENTER CONSOLE MULTI-FUNCTION SWITCH
ENGINE CONTROL MODULE
ENGINE OIL LEVEL SWITCH
EXCEPT 3.6L
HEATER COOLANT PUMP
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
PARK POSITION SWITCH
RIGHT REAR WINDOW DEFOGGER NOISE FILTER
SECONDARY IGNITION AIR INJECTION COIL 1 SOLENOID VALVE CYLINDER 3/4
STARTER/ GENERATOR COOLANT PUMP
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VALVE ASSEMBLY
WHT WIRE
Go to component: -> Ground distribution circuit (3 of 7) -> (ENGINE HARNESS, 4 CM FROM BRANCH TO ENGINE
