Chevrolet Impala IX (2006-2016) door lock ajar indicator switch ajar Wiring diagrams

This page contains all the electrical diagrams for the component. door lock ajar indicator switch ajar, in which he is found in the car Chevrolet Impala IX (2006-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram door lock ajar indicator switch ajar (1 of 2)

Wiring diagram door lock ajar indicator switch ajar for Chevrolet Impala IX (2006-2016)

Get access

AIR BAG DISPLAY FUSE AJAR DOOR LOCK AJAR INDICATOR SWITCH BLK WIRE COMPUTER DATA LINES SYSTEM LOW SPEED GMLAN SERIAL DATA DK GRN/BLK WIRE DOOR LOCK ACTUATOR DOOR LOCK AJAR INDICATOR AJAR DOOR LOCK AJAR INDICATOR SWITCH AJAR DOOR LOCK OPEN INDICATOR SWITCH OPEN DRIVER DOOR LOCK (DRIVER'S DOOR) DRIVER INFORMATION CENTER (DIC) DISPLAY GRY WIRE GRY/BLK WIRE HOT W/ IGN MAIN PCB RELAY ENERGIZED IGN INSTRUMENT PANEL CLUSTER (IPC) LEFT REAR DOOR LOCK (LEFT REAR DOOR) LOGIC LT BLU/BLK WIRE LT GRN/BLK WIRE OPEN DOOR LOCK OPEN INDICATOR SWITCH ORG/ WIRE PASSENGER DOOR LOCK (FRONT PASSENGER'S DOOR) PNK IGN 1 VOLT WIRE PNK WIRE PPL PPL 3 4 5 RIGHT REAR DOOR LOCK (RIGHT REAR DOOR) SECURITY IND SWITCH TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) W/ THEFT DETERRENT W/O THEFT DETERRENT

Go to component: -> Forced entry circuit (2 of 2) -> DOOR LOCK AJAR INDICATOR SWITCH AJAR
