Chevrolet Impala IX (2006-2016) can bus low 2 serial data Wiring diagram

BATT POS VOLT BATT POSIT VOLT BATTERY ENERGY CONTROL MODULE BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU/VIO WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE CAN BUS HIGH 2 SERIAL DATA CAN BUS LOW 2 SERIAL DATA COMPUTER DATA LINES SYSTEM COOLANT PUMP RLY COIL CTRL COOLANT TEMP SENS SIG DK BLU WIRE ENGINE CONTROL IGNITION RELAY FAN SPD SENS SUPPLY VOLT FAN SPD SIG (1) FAN SPD SIG (2) FUSE GRN WIRE GROUND GRY WIRE GRY/YEL WIRE HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA - HOT AT ALL TIMES HOT AT ALL TIMES BATTERY FUSE BLOCK FUSE HYBRID/EV BATTERY PACK (LUGGAGE COMPT, BEHIND REAR SEATS) HYBRID/EV BATTERY PACK COOLING FAN (RIGHT SIDE LUGGAGE COMPT) HYBRID/EV BATTERY SECTION 1 HYBRID/EV BATTERY SECTION 2 HYBRID/EV BATTERY TEMPERATURE SENSOR 1 HYBRID/EV BATTERY TEMPERATURE SENSOR 2 HYBRID/EV BATTERY TEMPERATURE SENSOR 3 HYBRID/EV BATTERY TEMPERATURE SENSOR 4 HYBRID/EV BATTERY TEMPERATURE SENSOR 5 HYBRID/EV BATTERY TEMPERATURE SENSOR 6 HYBRID/EV POWERTRAIN CONTROL MODULE STARTER/GENERATOR CONTROL MODULE INLET HYBRID/ EV BATTERY AIR PACK TEMPERATURE SENSOR LOGIC LT GRN/VIO WIRE MGU COOL PMP FUSE ORG/ WIRE ORG/GRY WIRE PNK/BLK WIRE POWER PACK FUSE RED WIRE RED/BRN WIRE RED/DK BLU WIRE SENS LOW REF STARTER/ GENERATOR COOLANT PUMP (ON RADIATOR FAN ASSEMBLY) STARTER/ GENERATOR COOLANT PUMP RELAY STARTER/ GENERATOR COOLANT TEMPERATURE SENSOR UNDERHOOD FUSE BLOCK VIO WIRE WAKEUP SER DATA WHT WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE
