Chevrolet Impala IX (2006-2016) (body harness, 7 cm forward of breakout Wiring diagrams

AMBIENT LIGHT/SUNLOAD SENSOR (TOP CENTER OF DASH) AUTOMATIC A/C BLK WIRE BLK/GRN WIRE BRN/DK GRN WIRE BRN/LT GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/LT GRN WIRE HVAC CONTROL MODULE HYBRID/EV BATTERY PACK (LUGGAGE COMPT, BEHIND REAR SEATS) LEFT REAR DOOR LATCH ASSEMBLY LOGIC LOGIC LEFT REAR WINDOW SWITCH LR DR AJAR SW SIG MANUAL A/C PASSENGER DOOR LATCH ASSEMBLY PASSENGER DOOR LOCK SWITCH PASSENGER WINDOW MOTOR PPL RF DR AJAR SW SIG STARTER/GENERATOR CONTROL MODULE VIO/YEL WIRE WHT/DK BLU WIRE YEL WIRE YEL/VIO WIRE

AMBIENT LIGHT/SUNLOAD SENSOR (TOP CENTER OF DASH) ANTENNA HVAC CONTROL MODULE AUTOMATIC A/C BLK WIRE BLK/GRN WIRE BRN/DK GRN WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COAX DK BLU WIRE DK BLU/WHT WIRE FM/RFR GRY WIRE GRY/BLK WIRE GRY/LT GRN WIRE GRY/WHT WIRE HYBRID/EV BATTERY PACK (LUGGAGE COMPT, BEHIND REAR SEATS) LEFT REAR DOOR LATCH ASSEMBLY LOGIC LOGIC LEFT REAR WINDOW SWITCH LR DR AJAR SW SIG MANUAL A/C PASSENGER DOOR LATCH ASSEMBLY PASSENGER WINDOW SWITCH PPL RADIO ANTENNA AMPLIFIER (RIGHT REAR PASSENGER COMPT, MOUNTED TO C-PILLAR) REAR COMPARTMENT LID LATCH RECEIVE SIG REMOTE ACTR REMOTE ACTR RTN REMOTE CONTROL DOOR LOCK RECEIVER (UNDER DEFROSTER GRILL PANEL) RF DR AJAR SW SIG RFR STARTER/GENERATOR CONTROL MODULE SUPPLY VOLT TRANS SIG VIO/GRY WIRE VIO/YEL WIRE WHT/DK BLU WIRE YEL WIRE YEL/LT GRN WIRE

AMBIENT LIGHT/SUNLOAD SENSOR (TOP CENTER OF DASH) AUTOMATIC A/C BLK WIRE BLK/GRN WIRE BRN/DK GRN WIRE BRN/LT GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/LT GRN WIRE HVAC CONTROL MODULE HYBRID/EV BATTERY PACK (LUGGAGE COMPT, BEHIND REAR SEATS) LEFT REAR DOOR LATCH ASSEMBLY LOGIC LOGIC LEFT REAR WINDOW SWITCH LR DR AJAR SW SIG MANUAL A/C PASSENGER DOOR LATCH ASSEMBLY PASSENGER DOOR LOCK SWITCH PASSENGER WINDOW MOTOR PPL RF DR AJAR SW SIG STARTER/GENERATOR CONTROL MODULE VIO/YEL WIRE WHT/DK BLU WIRE YEL WIRE YEL/VIO WIRE

AMBIENT LIGHT/SUNLOAD SENSOR (TOP CENTER OF DASH) ANTENNA HVAC CONTROL MODULE AUTOMATIC A/C BLK WIRE BLK/GRN WIRE BRN/DK GRN WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COAX DK BLU WIRE DK BLU/WHT WIRE FM/RFR GRY WIRE GRY/BLK WIRE GRY/LT GRN WIRE GRY/WHT WIRE HYBRID/EV BATTERY PACK (LUGGAGE COMPT, BEHIND REAR SEATS) LEFT REAR DOOR LATCH ASSEMBLY LOGIC LOGIC LEFT REAR WINDOW SWITCH LR DR AJAR SW SIG MANUAL A/C PASSENGER DOOR LATCH ASSEMBLY PASSENGER WINDOW SWITCH PPL RADIO ANTENNA AMPLIFIER (RIGHT REAR PASSENGER COMPT, MOUNTED TO C-PILLAR) REAR COMPARTMENT LID LATCH RECEIVE SIG REMOTE ACTR REMOTE ACTR RTN REMOTE CONTROL DOOR LOCK RECEIVER (UNDER DEFROSTER GRILL PANEL) RF DR AJAR SW SIG RFR STARTER/GENERATOR CONTROL MODULE SUPPLY VOLT TRANS SIG VIO/GRY WIRE VIO/YEL WIRE WHT/DK BLU WIRE YEL WIRE YEL/LT GRN WIRE
