Chevrolet Impala IX (2006-2016) antenna sig hi antenna sig lo Wiring diagrams

This page contains all the electrical diagrams for the component. antenna sig hi antenna sig lo, in which he is found in the car Chevrolet Impala IX (2006-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram antenna sig hi antenna sig lo (1 of 2)

Wiring diagram antenna sig hi antenna sig lo for Chevrolet Impala IX (2006-2016)

Get access

ANTENNA SIG HI ANTENNA SIG HI ANTENNA SIG LO ANTENNA SIG LO BLK WIRE BLU WIRE BRN/LT GRN WIRE BRN/YEL WIRE CO-DRV DR ANT SIG HI CO-DRV DR HANDLE SW SIG DRV DR HANDLE SW SIG DRIVER EXTERIOR DOOR HANDLE ASSEMBLY DRIVER EXTERIOR DRIVER DOOR DOOR HANDLE HANDLE KEYLESS SWITCH ENTRY ANTENNA EXTERIOR DOOR HANDLE SWITCH GRY WIRE GRY/BLK WIRE GRY/LT GRN WIRE KEYLESS ENTRY CONTROL MODULE (RIGHT A-PILLAR) LEFT REAR EXTERIOR DOOR HANDLE ASSEMBLY LEFT REAR EXTERIOR DOOR HANDLE SWITCH LOGIC RIGHT REAR WINDOW SWITCH LT GRN/BLK WIRE LT GRN/GRY WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE PASSENGER DOOR HANDLE KEYLESS ENTRY ANTENNA REAR FASCIA KEYLESS ENTRY ANTENNA RED WIRE RIGHT REAR RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR EXTERIOR DOOR HANDLE ASSEMBLY RR DR AJAR SW SIG VIO WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/DK BLU WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> Forced entry circuit, with passive keyless entry (4 of 4) -> ANTENNA SIG HI ANTENNA SIG LO

Wiring diagram antenna sig hi antenna sig lo (2 of 2)

Wiring diagram antenna sig hi antenna sig lo for Chevrolet Impala IX (2006-2016)

Get access

ANTENNA SIG HI ANTENNA SIG HI ANTENNA SIG LO ANTENNA SIG LO BLK WIRE BLU WIRE BRN/LT GRN WIRE BRN/YEL WIRE CO-DRV DR ANT SIG HI CO-DRV DR HANDLE SW SIG DRV DR HANDLE SW SIG DRIVER EXTERIOR DOOR HANDLE ASSEMBLY DRIVER EXTERIOR DRIVER DOOR DOOR HANDLE HANDLE KEYLESS SWITCH ENTRY ANTENNA EXTERIOR DOOR HANDLE SWITCH GRY WIRE GRY/BLK WIRE GRY/LT GRN WIRE KEYLESS ENTRY CONTROL MODULE (RIGHT A-PILLAR) LEFT REAR EXTERIOR DOOR HANDLE ASSEMBLY LEFT REAR EXTERIOR DOOR HANDLE SWITCH LOGIC RIGHT REAR WINDOW SWITCH LT GRN/BLK WIRE LT GRN/GRY WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE PASSENGER DOOR HANDLE KEYLESS ENTRY ANTENNA REAR FASCIA KEYLESS ENTRY ANTENNA RED WIRE RIGHT REAR RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR EXTERIOR DOOR HANDLE ASSEMBLY RR DR AJAR SW SIG VIO WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/DK BLU WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> Power door locks circuit, with passive keyless entry (4 of 4) -> ANTENNA SIG HI ANTENNA SIG LO
