Chevrolet Impala IX (2006-2016) 2500 2501 6045 computer data lines system Wiring diagram

This page shows the only wiring diagram for the component.2500 2501 6045 computer data lines system, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 2500 2501 6045 computer data lines system (1 of 1)

Wiring diagram 2500 2501 6045 computer data lines system for Chevrolet Impala IX (2006-2016)

Get access

1 2 3 4 5 6 7 8 9 10 SERIAL DATA + SERIAL DATA - SERIAL DATA + SERIAL DATA - 1 2 3 4 5 6 DATA (-) DATA (-) DATA (+) DATA (+) VOLT GND 1 2 BATT POS VOLT GND 2500 2501 6045 COMPUTER DATA LINES SYSTEM 9 8 17 DATA + DATA - SPLY VOLT BATTERY FUSE BLOCK BLK WIRE BLK/BRN WIRE COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/YEL WIRE DRIVER INFORMATION CENTER DISPLAY ELECTRONIC BRAKE CONTROL MODULE (IN BRAKE PRESSURE MODULATOR VALVE) FUSE HOT AT ALL TIMES INSTRUMENT CLUSTER LOGIC LT GRN WIRE POWER STEERING CONTROL MODULE (MOUNTED TO STEERING GEAR) RED/YEL WIRE SERIAL DATA + SERIAL DATA - SERIAL DATA + SERIAL DATA - SERIAL DATA + STEERING ANGLE SENSOR (BASE OF STEERING COLUMN) SYSTEM WHT WIRE WHT/DK BLU WIRE

Go to component: -> Electronic power steering circuit, with belt drive -> 2500 2501 6045 COMPUTER DATA LINES SYSTEM
