Chevrolet Impala IX (2006-2016) 22 21 lo spd gmlan ser data network bus 4 Wiring diagram

1 3 HI SPD GMLAN SER DATA (-) 2 HI SPD GMLAN SER DATA (+) 2 2 4 HI SPD GMLAN SER DATA (-) 2 HI SPD GMLAN SER DATA (+) 2 22 21 LO SPD GMLAN SER DATA NETWORK BUS 4 22 23 20 ACC WAKEUP SER DATA SER DATA COMM ENABLE B+ 25 24 HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SER DATA (-) 1 BLK WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE CENTER CONSOLE MULTIFUNCTION SWITCH (W/ HEATED SEATS) COMPASS MODULE (IF EQUIPPED) (TOP OF REAR WINDOW SHELF) DATA LINK CONNECTOR (LEFT SIDE OF DASH) DK BLU WIRE DK BLU/YEL WIRE FRONT SEAT HEATING CONTROL MODULE (IF EQUIPPED) GRN/PPL WIRE GRY/VIO WIRE HYBRID EXCEPT HYBRID W/ BELT DRIVE W/O BELT DRIVE 2 3 4 LEFT REAR WINDOW SWITCH LOGIC LOGIC DRIVER WINDOW MOTOR LOGIC DRIVER WINDOW SWITCH LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK BLU WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE NETWORK BUS 1 NETWORK BUS 11 NETWORK BUS 2 NETWORK BUS 3 NETWORK BUS 4 RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR WINDOW SWITCH STEERING WHEEL ANGLE SENSOR (BASE OF STEERING COLUMN) SUNROOF MOTOR (IF EQUIPPED) (FRONT CENTER OF SUNROOF MODULE) SUNROOF SUNSHADE MOTOR MODULE (IF EQUIPPED) TRANSMISSION SHIFT LEVER POSITION INDICATOR VIO/YEL WIRE W/ KEYLESS ENGINE START SWITCH WHT WIRE WHT/DK BLU WIRE WHT/GRN WIRE WHT/VIO WIRE
