Access panel release circuit for Chevrolet HHR I (2005-2011)
Access panel release circuit
22 7 LOCK CTRL SW SIG
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DK BLU WIRE
DOOR LOCK RELAY
DRIVER LEFT REAR ACCESS PANEL RELEASE SWITCH
DRIVER RIGHT REAR ACCESS PANEL RELEASE SWITCH
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
L/GATE/ S/ROOF FUSE 10
LEFT REAR ACCESS PANEL LOCK
LEFT REAR ACCESS PANEL RELAY
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
PASSENGER RIGHT REAR ACCESS PANEL RELEASE SWITCH
REAR ACCESS PANEL FUSE BLOCK (PANEL VAN) (RIGHT REAR OF CARGO AREA)
RED/WHT WIRE
RIGHT REAR ACCESS PANEL LOCK
RIGHT REAR ACCESS PANEL RELAY
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
UNDERHOOD RELAY BLOCK
