Backup lamps circuit for Chevrolet HHR I (2005-2011)
Backup lamps circuit
2.0L
A/T
BACKUP LAMP SPLY VOLT LOGIC REARVIEW CAMERA INSIDE REAR- VIEW MIRROR (ISRVM)
BACKUP LAMP SWITCH (LEFT SIDE OF ENGINE COMPT, ON TRANSMISSION ASSEMBLY)
BACKUP/LPS FUSE
BLK WIRE
EXCEPT 2.0L
HOT W/ RUN/CRANK RELAY ENERGIZED
LEFT BACKUP LAMP
LT GRN WIRE
M/T
NCA WIRE
PARK NEUTRAL POSITION (PNP) SWITCH (TOP OF AUTOMATIC TRANSMISSION)
PNK WIRE
RIGHT BACKUP LAMP
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
W/ REARVIEW CAMERA
W/O REARVIEW CAMERA
