Chevrolet HHR I (2005-2011) ppl sunroof switch open vent signal Wiring diagram
This page shows the only wiring diagram for the component.ppl sunroof switch open vent signal, which is found in the car Chevrolet HHR I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl sunroof switch open vent signal (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK WIRE
BRN WIRE
CONFIG 1
CONFIG 2
CONFIG 3
DK GRN WIRE
GROUND
HOT AT ALL TIMES
L/GATE/ S/ROOF FUSE 10
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK SUNROOF SWITCH EXPRESS VENT SIGNAL WIRE
PNK WIRE
PPL
PPL SUNROOF SWITCH OPEN VENT SIGNAL
RED/WHT WIRE
ROOF CLOSE
ROOF EXPRESS
ROOF OPEN
SUNROOF CONTROL MODULE (CENTER OF HEADLINER)
SUNROOF ENABLE SIGNAL
SUNROOF MOTOR
SUNROOF SWITCH
SUNROOF SWITCH CLOSE SIGNAL
SUNROOF SWITCH CLOSE VENT SIGNAL
SUNROOF SWITCH EXPRESS SIGNAL
SUNROOF SWITCH OPEN SIGNAL
TAN WIRE
UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
VENT CLOSE
VENT EXPRESS
VENT OPEN
WHT WIRE
WHT/BLU WIRE
WHT/DK GRN WIRE
WHT/RED WIRE
Go to component -> Power top/sunroof circuit -> PPL SUNROOF SWITCH OPEN VENT SIGNAL
