Chevrolet HHR I (2005-2011) logic security ind supply voltage Wiring diagram
This page shows the only wiring diagram for the component.logic security ind supply voltage, which is found in the car Chevrolet HHR I (2005-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram logic security ind supply voltage (1 of 1)
2500 2501 COMPUTER DATA LINES SYSTEM
43 44 GMLAN SERIAL DATA + GMLAN SERIAL DATA -
6 10 7 8 FUEL INJ 1 CTRL FUEL INJ 2 CTRL FUEL INJ 3 CTRL FUEL INJ 4 CTRL
A/T
A/T M/T
ACC VOLT
B(+)
BATTERY (B+)
BETWEEN DOOR HINGES)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CLSTR FUSE 7
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
ENGINE CONTROLS SYSTEM
EXCEPT PANEL VAN
FUSE 10
GMLAN SERIAL DATA
GMLAN SERIAL DATA - GMLAN SERIAL DATA +
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
HEADLIGHTS SYSTEM
HOOD AJAR SWITCH
HORN RELAY CTRL
HORNS SYSTEM
HOT AT ALL TIMES
HVAC
IGN KEY RESISTOR SIG
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LEFT REAR ACCESS PANEL LATCH (REAR OF LEFT REAR ACCESS PANEL)
LOGIC
LOGIC SECURITY IND SUPPLY VOLTAGE
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT LT
M/T
OFF
OFF/RUN/CRANK
PANEL VAN
PARK LAMP RELAY CTRL
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL 3 4 19 20 1 22
RED WIRE
RED/WHT WIRE
RELAY CTRL
RIGHT FRONT DOOR JAMB SWITCH (RIGHT "A" PILLAR
RUN WIRE
SECURITY IND
SECURITY INDICATOR
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
W/ ONSTAR
W/ REMOTE KEYLESS ENTRY LOCK CONTROL
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
XM/ ONSTAR FUSE 24
Go to component -> Anti-theft circuit -> LOGIC SECURITY IND SUPPLY VOLTAGE
