Chevrolet HHR I (2005-2011) compartment, next to left strut tower) Wiring diagrams
This page contains all the electrical diagrams for the component. compartment, next to left strut tower), in which he is found in the car Chevrolet HHR I (2005-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram compartment, next to left strut tower) (1 of 2)
B(+)
BLK WIRE
CLASS 2 SERIAL DATA
COMPARTMENT, NEXT TO LEFT STRUT TOWER)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DK GRN/BLK WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ELECTRIC POWER STEERING (EPS) MOTOR
EPS FUSE 1
EPS/STR WHL CNTRL
FUSE 19
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN RUN OR START
IGN 1 VOLT LEFT ASSIST MOTOR CTRL
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
PNK PNK WIRE
PNK WIRE
POWER STEERING CONTROL MODULE (PSCM)
RED WIRE
RED/BLK WIRE
RIGHT ASSIST MOTOR CTRL
STEERING COLUMN)
STEERING SHAFT TORQUE SENSOR
TAN WIRE
UNDERHOOD FUSE BLOCK (IN ENGINE
Go to component -> 2.2l vin b, electronic power steering circuit -> COMPARTMENT, NEXT TO LEFT STRUT TOWER)
Wiring diagram compartment, next to left strut tower) (2 of 2)
B(+)
BLK WIRE
CLASS 2 SERIAL DATA
COMPARTMENT, NEXT TO LEFT STRUT TOWER)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DK GRN/BLK WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ELECTRIC POWER STEERING (EPS) MOTOR
EPS FUSE 1
EPS/STR WHL CNTRL
FUSE 19
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN RUN OR START
IGN 1 VOLT LEFT ASSIST MOTOR CTRL
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
PNK PNK WIRE
PNK WIRE
POWER STEERING CONTROL MODULE (PSCM)
RED WIRE
RED/BLK WIRE
RIGHT ASSIST MOTOR CTRL
STEERING COLUMN)
STEERING SHAFT TORQUE SENSOR
TAN WIRE
UNDERHOOD FUSE BLOCK (IN ENGINE
Go to component -> 2.4l vin v, electronic power steering circuit -> COMPARTMENT, NEXT TO LEFT STRUT TOWER)
