Chevrolet HHR I (2005-2011) 44 54 71 hi beam rly ctrl fog lmp rly ctrl drl relay ctrl wiring diagram

44 54 71 HI BEAM RLY CTRL FOG LMP RLY CTRL DRL RELAY CTRL AMBIENT LIGHT SENSOR BLK WIRE BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/BLK WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY DRL FUSE DRL RELAY FOG LAMP FOG LAMP FUSE FOG LAMP IND IGN HIGH BEAM IND FOG LAMP RELAY FOG LAMP SWITCH FTP GRY WIRE HEAD HI BEAM RELAY HIGH BEAM HOT AT ALL TIMES IGN INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT LEFT HEADLAMP LO BEAM RELAY LOGIC LOW BEAM LOW FTP LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT HI BEAM FUSE LT LO BEAM FUSE OFF AUTO PARK ORG/ WIRE PARK BRAKE SWITCH (IN CENTER CONSOLE, ATTACHED TO EMERGENCY BRAKE) PARK BRK SW SIG PNK WIRE PNK/WHT WIRE PPL PPL/WHT WIRE RIGHT FRONT FOG LAMP RIGHT HEADLAMP RT HI BEAM FUSE RT LO BEAM FUSE SERIAL DATA TAN WIRE TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, NEXT TO LEFT STRUT TOWER) WHT WIRE YEL WIRE YEL/BLK WIRE
