Chevrolet Forward Control P30 (1985-1999) turn-b/u fuse Wiring diagrams
This page contains all the electrical diagrams for the component. turn-b/u fuse, in which he is found in the car Chevrolet Forward Control P30 (1985-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
turn-b/u fuse wiring diagram (1 of 16)
BLK WIRE
BLU WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE BLOCK- I/P
GRN WIRE
HAZARD
HAZARD FLASHER (RIGHT SIDE OF STEERING COLUMN)
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P DIMMER SWITCH
INSTRUMENT CLUSTER
LEFT FRONT MARKER LAMP
LEFT LICENSE LAMP
LEFT TAIL/STOP TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
LT LT
NORMAL
OFF
ORG/ WIRE
PARK
PPL
PROVISIONS FOR PARK LAMPS
PROVISIONS FOR REAR MARKER LAMPS
RIGHT BACKUP LAMP LEFT BACKUP LAMP
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN LAMP LEFT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP RIGHT TAIL/STOP/ TURN LAMP
RIGHT TURN INDICATOR
STOP/ HAZ FUSE
TAIL LPS FUSE
TURN LEFT
TURN RIGHT
TURN SIGNAL FLASHER
TURN-B/U FUSE
TURN/HAZARD SWITCH (LEFT SIDE OF STEERING COLUMN)
WHT WIRE
YEL WIRE
Go to component -> Exterior light circuit, commercial chassis -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (2 of 16)
BACKUP LAMP SWITCH (ON STEERING COLUMN)
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE BLOCK (BEHIND LEFT SIDE OF I/P)
G# N/A (IN REAR LAMPS HARNESS)
GRN WIRE
HAZARD
HAZARD FLASHER
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT BACKUP LAMP RIGHT BACKUP LAMP
LEFT FRONT MARKER LAMP
LEFT LICENSE LAMP
LEFT PARK LAMP
LEFT TAIL/STOP TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT LT
NORMAL
OFF
ORG/ WIRE
PARK
PPL
PROVISIONS FOR CLEARANCE LAMPS
PROVISIONS FOR REAR MARKER LAMPS
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN LAMP LEFT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP
RIGHT PARK LAMP
RIGHT TAIL/STOP TURN LAMP
RIGHT TURN INDICATOR
STOP/ HAZ FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
TAIL LPS FUSE
TURN LEFT
TURN RIGHT
TURN SIGNAL FLASHER
TURN-B/U FUSE
TURN/HAZARD SWITCH (ON MULTI- FUNCTION LEVER)
WHT WIRE
YEL WIRE
Go to component -> Exterior light circuit, cutaway chassis -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (3 of 16)
BACKUP LAMP SWITCH (ON STEERING COLUMN)
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE BLOCK- I/P
G# N/A (REAR LAMPS HARNESS)
GRN WIRE
HAZARD
HAZARD FLASHER (TOP LEFT SIDE OF SHIPPING PANEL)
HEAD OFF
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT FRONT MARKER LAMP
LEFT LICENSE LAMP RIGHT LICENSE LAMP
LEFT TAIL/STOP TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT LT
NORMAL
ORG/ WIRE
PARK
PPL
PROVISIONS FOR BODY BUILDER ADDED LAMPS
PROVISIONS FOR REAR MARKER LAMPS
RIGHT BACKUP LAMP LEFT BACKUP LAMP
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN LAMP LEFT FRONT PARK/ TURN LAMP
RIGHT TAIL/STOP TURN LAMP
RIGHT TURN INDICATOR
STOP/ HAZ FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT)
TAIL LPS FUSE
TURN LEFT
TURN RIGHT
TURN SIGNAL FLASHER
TURN-B/U FUSE
TURN/HAZARD SWITCH (UPPER LEFT SIDE OF STEERING COLUMN)
WHT WIRE
YEL WIRE
Go to component -> Exterior light circuit, motor home chassis -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (4 of 16)
BACKUP LAMP SWITCH (ON STEERING COLUMN)
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
FUSE BLOCK- I/P
G# N/A (LEFT SHIPPING (PANEL)
G# N/A (REAR LAMPS HARNESS)
GRN WIRE
HAZARD
HAZARD FLASHER (TOP LEFT SIDE OF SHIPPING PANEL)
HEAD
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
INSTRUMENT CLUSTER
LEFT BACKUP LAMP RIGHT BACKUP LAMP
LEFT FRONT MARKER LAMP
LEFT LICENSE LAMP
LEFT TAIL/STOP TURN LAMP
LEFT TURN INDICATOR
LIGHT SWITCH ASSEMBLY
LT BLU WIRE
LT LT
NORMAL
OFF
ORG/ WIRE
PARK
PPL
PROVISIONS FOR BODY BUILDER ADDED LAMPS
PROVISIONS FOR MARKER LAMPS
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN LAMP LEFT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP
RIGHT TAIL/STOP TURN LAMP
RIGHT TURN INDICATOR
STOP/ HAZ FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT)
TAIL LPS FUSE
TURN FLASHER
TURN LEFT
TURN RIGHT
TURN SIGNAL SWITCH (LEFT SIDE OF STEERING COLUMN)
TURN-B/U FUSE
WHT WIRE
YEL WIRE
Go to component -> Exterior light circuit, motorhome chassis -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (5 of 16)
1995 VFTC
ALT FUSE
AUDIO ALARM MODULE
BACKUP LAMP SWITCH (MANUAL TRANS) BACKUP LAMP SWITCH (AUTO TRANS)
COLD ADVANCE FAST IDLE TEMPERATURE SWITCH WATER-IN-FUEL SENSOR
CONVENIENCE CENTER
DK BLU WIRE
ECM CRANK FUSE
FROM FUSIBLE LINK A
FROM IGNITION SWITCH
FUEL HEATER GENERATOR
FUSE BLOCK
GLOW PLUG CONTROLLER
I/P CLUSTER
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE
RED WIRE
TCC/ BRAKE SWITCH
TRANS FUSE
TRANSMISSION
TRANSMISSION CONTROL MODULE
TURN SIGNAL FLASHER
TURN-B/U FUSE
VEHICLE SPEED SENSOR BUFFER
WITH AUTOMATIC TRANSMISSION ONLY
Go to component -> Power distribution circuit, commercial chassis (diesel) (2 of 2) -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (6 of 16)
ALT FUSE
AUDIO ALARM MODULE
BACKUP LAMP SWITCH
CONVENIENCE CENTER
DK BLU WIRE
ECM CRANK FUSE
EVAPORATIVE CANISTER PURGE SOLENOID
FUSE BLOCK
I/P CLUSTER
IDLE SPEED CONTROL ACTUATOR
IGNITION COIL
IGNITION SWITCH
INJ FUSE
INJECTOR 1
INJECTOR 2
KNOCK SENSOR SYSTEM
PNK WIRE
PNK/BLK WIRE
RED WIRE
TCC/ BRAKE SWITCH
TRANS FUSE
TRANSMISSION
TRANSMISSION CONTROL MODULE
TURN SIGNAL FLASHER
TURN-B/U FUSE
VEHICLE SPEED SENSOR BUFFER
VIN N W/ AUTOMATIC TRANSMISSION
W/ AUTOMATIC TRANSMISSION
WHT WIRE
Go to component -> Power distribution circuit, commercial chassis (gasoline) (2 of 2) -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (7 of 16)
ALT FUSE
AUDIO ALARM MODULE
BACKUP LAMP SWITCH
CRUISE CONTROL BRAKE SWITCH
CRUISE CONTROL MODULE
CRUISE CONTROL SWITCH
DK BLU WIRE
ECM CRANK FUSE
EVAPORATIVE EMISSIONS CANISTER PURGE SOLENOID
FUSE BLOCK
GENERATOR
IDLE SPEED CONTROL ACTUATOR
IGNITION COIL
IGNITION SWITCH
INJ FUSE
INJECTOR 1
INJECTOR 2
INSTRUMENT CLUSTER PRINTED CIRCUIT
LINEAR EGR SOLENOID VALVE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
TCC/ STOPLAMP SWITCH
TRANS FUSE
TRANSMISSION
TURN SIGNAL FLASHER
TURN-B/U FUSE
VEHICLE SPEED SENSOR BUFFER
WHT WIRE
Go to component -> Power distribution circuit, motorhome chassis (2 of 2) -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (8 of 16)
85 30 PPL
BLK WIRE
BRAKE/
BRAKE/TRANSMISSION SHIFT INTERLOCK (BTSI) SOLENOID (ON STEERING COLUMN)
BRN WIRE
DIESEL
DIESEL ONLY
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (BELOW RADIATOR ON CROSSMEMBER)
GASOLINE
HOT IN RUN
I-3 FUSE
I/P FUSE BLOCK
PARK/NEUTRAL POSITION AND BACKUP LAMPS SWITCH (LEFT OF TRANS)
PPL
TORQUE CONVERTER CLUTCH AND STOP LAMPS SWITCH (RIGHT SIDE OF STEERING COLUMN)
TRANS- MISSION CONTROL MODULE (TCM) (LEFT INTERIOR FIREWALL)
TURN SIGNAL FLASHER (ON FUSE BLOCK)
TURN-B/U FUSE
VEHICLE CONTROL MODULE (VCM) (LEFT SIDE OF ENG COMPT) IGN
YEL WIRE
Go to component -> Shift interlock circuit, commercial chassis -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (9 of 16)
1995 VFTC
BACKUP LAMP SWITCH (ON STEERING COLUMN)
BLK WIRE
BRAKE SHIFT INTERLOCK RELAY (ON STEERING COLUMN)
BRAKE/TRANSMISSION SHIFT INTERLOCK SOLENOID (ON STEERING COLUMN)
DK BLU WIRE
DK GRN/WHT WIRE
FUSE BLOCK
HOT IN ACC OR RUN
HOT IN START OR RUN
PNK/BLK WIRE
PPL
PPL PPL
PPL PPL ENGINE CONTROLS SYSTEM
TCC/ BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
TRANS FUSE
TURN SIGNAL FLASHER (ON FUSE BLOCK)
TURN-B/U FUSE
Go to component -> Shift interlock circuit, cutaway chassis -> TURN-B/U FUSE
turn-b/u fuse wiring diagram (10 of 16)
BACKUP LAMP SWITCH
BLK WIRE
BRAKE SHIFT INTERLOCK RELAY (ON STEERING COLUMN)
BRAKE/TRANSMISSION SHIFT INTERLOCK SOLENOID (ON STEERING COLUMN)
CLOSED IN PARK
DK BLU WIRE
DK GRN/WHT WIRE
FUSE BLOCK
HOT IN ACC OR RUN
HOT IN START OR RUN FUSE BLOCK TRANS FUSE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF VEHICLE, BEHIND SHIPPING PANEL)
PPL
PPL PPL
TCC/ BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
TURN SIGNAL FLASHER (ON FUSE BLOCK)
TURN-B/U FUSE
Go to component -> Shift interlock circuit, motorhome chassis -> TURN-B/U FUSE
