Chevrolet Forward Control P30 (1985-1999) service trans Wiring diagram
This page shows the only wiring diagram for the component.service trans, which is found in the car Chevrolet Forward Control P30 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram service trans (1 of 1)
"WAIT TO START" GLOW PLUGS
1-2 SHIFT SOLENOID
2-3 SHIFT SOLENOID
A/T
AUTOMATIC TRANSMISSION (REAR OF ENGINE)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
ECM 1 FUSE 12
ECM-BAT FUSE 6
FUEL INJECTION PUMP SHUT-OFF SOLENOID (AT FUEL INJECTION PUMP)
FUEL LIFT PUMP (ON INSIDE RIGHT FRAME RAIL)
FUEL PUMP RELAY (ON ENGINE FIREWALL BRACKET, UNDER BATTERY JUNCTION BLOCK)
GAUGES FUSE 8
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (BEHIND DASH PANEL) (BODY BUILDER INSTALLED)
INSTRUMENT CLUSTER
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
M/T
NCA WIRE
ORN/
PNK 3 4 5 6 7 8 WIRE
PNK WIRE
PRESSURE CONTROL SOLENOID
RED WIRE
RED/BLK WIRE
SERVICE TRANS
SPEEDO- METER
TCC PWM SOLENOID
TRANS FUSE 17
TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
TRANSMISSION RANGE (TR) PRESSURE SWITCH ASSEMBLY
WATER IN FUEL
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.5l (vin y)s, commercial chassis - mechanical (2 of 3) -> SERVICE TRANS
