Chevrolet Forward Control P30 (1985-1999) service engine soon lamp Wiring diagram
This page shows the only wiring diagram for the component.service engine soon lamp, which is found in the car Chevrolet Forward Control P30 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram service engine soon lamp (1 of 1)
"SERVICE THROTTLE" LAMP
12 13 PNK WIRE
A/C SIG
AIR CONDITIONING SYSTEM
APP 3 SENS SIG FUEL TEMP SIG IAT SIG
BARO SENSOR (NO LOCATION AVAILABLE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ECM-CRNK FUSE
FUEL HEATER (NO LOCATION AVAILABLE)
FUEL PUMP (NO LOCATION AVAILABLE)
FUEL PUMP OIL PRESSURE SWITCH
FUEL PUMP RELAY (NO LOCATION AVAILABLE)
FUSIBLE LINK
FUSIBLE LINKS
GLOW PLUG CONTROL RELAY (RIGHT REAR TOP OF ENGINE)
GLOW PLUG SIG
GROUND (NO LOCATION AVAILABLE)
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK STOP FUSE
HOT IN RUN, BULB TEST OR START
HOT IN START OR RUN ALT FUSE
IGNITION FEED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTERS SYSTEM
LEFT BANK GLOW PLUGS
LT GRN WIRE
LT GRN/WHT WIRE
MANIFOLD ABSOLUTE PRESSURE SENSOR (NO LOCATION AVAILABLE)
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF DRIVER'S ISLAND)
PPL 15 16
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RIGHT BANK GLOW PLUGS
SERVICE ENGINE SOON LAMP
STARTING/ CHARGING SYSTEM
STOP LAMP/ CRUISE CONTROL BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
TAN WIRE
TCC BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) PPL
WAIT LAMP
WASTEGATE SOL CTRL
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.5l (vin f)s (2 of 2) -> SERVICE ENGINE SOON LAMP
