Chevrolet Forward Control P30 (1985-1999) pnk dimmer switch Wiring diagram
This page shows the only wiring diagram for the component.pnk dimmer switch, which is found in the car Chevrolet Forward Control P30 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk dimmer switch (1 of 1)
6.5L VIN F
AUTO APPLY FUSE 19
AUTOMATIC TRANSMISSION
BRN WIRE
CRANK FUSE 18
DAYTIME RUNNING LAMP CONTROL MODULE
DIESEL
DIODE NETWORK
DK BLU WIRE
ENG-1 FUSE TRANS FUSE 17
ENGINE SHUT OFF SOLENOID
EVAPORATIVE EMISSIONS CANISTER PURGE VALVE SOLENOID
FROM FUSE PANEL)
FROM FUSIBLE LINK (DIAGRAM 1 OF 4)
FROM I/P FUSE BLOCK) PNK WIRE
FUEL SOLENOID DRIVER
HARN BREAKOUT) PNK WIRE
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 1 CAMSHAFT POSITION SENSOR FAN CONTROL RELAY
HEATED OXYGEN SENSOR BANK 2 SENSOR 2
I/P FUSE BLOCK (MOUNTED ON THE DASH)
IGNITION SWITCH
INSTRUMENT CLUSTER BREAKOUT)
INSTRUMENT CLUSTER ENGINE COOLANT LEVEL SWITCH
LOCK OFF
LT BLU WIRE
MASS AIR FLOW SENSOR HEATED OXYGEN SENSOR BANK 1 SENSOR 1
NCA WIRE
ORG/ WIRE
PARK BRAKE ALARM
PARK BRAKE ALARM RELAY
PARK BRAKE LOW PRESSURE INDICATOR SWITCH PARK BRAKE PULL BUTTON SWITCH
PARK BRAKE PULL BUTTON RELAY
PARK BRAKE SWITCH
PARK/ NEUTRAL POSITION AND BACKUP LAMPS SWITCH
PARK/NEUTRAL POSITION AND BACKUP LAMPS SWITCH
PASSTHROUGH 6.5L: ENG HARN,
PNK DIMMER SWITCH WIRE
PNK PNK WIRE
PNK WIRE
RADIO FUSE 4
RED WIRE
RELAY SOCKETS)
RUN WIRE
TO AUX FUSE (DIAGRAM 4 OF 4)
TO GAUGES FUSE (DIAGRAM 4 OF 4)
WHT WIRE
WINDSHIELD WIPER MOTOR
WIPER FUSE 14
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit, motor home chassis (2 of 4) -> PNK DIMMER SWITCH WIRE
