Chevrolet Forward Control P30 (1985-1999) pickup coil Wiring diagram

BATTERY JUNCTION BLOCK (ON FORWARD LEFT SIDE OF BULKHEAD) BLK WIRE BLK/RED WIRE BRN WIRE BRN/WHT WIRE BYPASS DIST. REF HI DIST. REF LO DISTRIBUTOR DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM 1 FUSE FUEL GAUGE FUEL PUMP PRIME CONNECTOR FUEL PUMP RELAY (AT RELAY CENTER RIGHT SIDE OF MAIN SUPPORT AT DRIVER'S ISLAND) FUEL PUMP, SENDER (ON TOP OF FUEL TANK) FUSIBLE LINK (16 GA- GAUGES FUSE GRY WIRE HIGH VOLTAGE IGNITION COIL WIRE HOT AT ALL TIMES HOT IN RUN, START (CRANK) I/P FUSE BLOCK (MOUNTED ON THE I/P) IGNITION COIL (ON BRACKET AT REAR OF INTAKE PLENUM) IGNITION MODULE IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF OIL PRESS GAUGE ORG/ WIRE PICKUP COIL PNK 9 10 11 12 13 14 15 16 WIRE PNK PNK 1 2 3 4 5 WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE RUN WIRE SERVICE ENGINE SOON INDICATOR SPEED METER TACHOMETER TEST LEAD TAN WIRE TAN/BLK WIRE THROTTLE BODY FUEL INJECTOR NO.1 (ON TOP OF INTAKE MANIFOLD) THROTTLE BODY FUEL INJECTOR NO.2 (ON TOP OF INTAKE MANIFOLD) WHT WIRE
