Chevrolet Forward Control P30 (1985-1999) daytime running lamp relay instrument cluster Wiring diagram
This page shows the only wiring diagram for the component.daytime running lamp relay instrument cluster, which is found in the car Chevrolet Forward Control P30 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram daytime running lamp relay instrument cluster (1 of 1)
1996 VFTC
6.5L ENGINE
A/C COMPRESSOR RELAY
A/T
AUX CIRCUIT BREAKER 13
AUX FUSE
BACK UP LAMPS SWITCH
BRN WIRE
CB CB I-3 FUSE 9
DAYTIME RUNNING LAMP RELAY INSTRUMENT CLUSTER
DAYTIME RUNNING LAMPS CONTROL MODULE
DIESEL
DK GRN WIRE
ECM 1 FUSE 12
ELECTRONIC BRAKE CONTROL MODULE
FROM ENG-1 FUSE (DIAGRAM 2 OF 4)
FROM IGNITION SWITCH (DIAGRAM 2 OF 4)
FROM VCM BREAKOUT)
FUEL INJECTION PUMP SHUT-OFF SOLENOID
GAS
GAUGES FUSE 8
GENERATOR GENERATOR
GLOW PLUG CONTROLLER (FEDERAL)
GRY WIRE
HTR BUS
HTR FUSE 1
I/P FUSE BLOCK (DASH PANEL PROVIDED BY BODY BUILDER)
IGN BUS
INSTRUMENT CLUSTER
INSTRUMENT LAMPS FUSE
INTERIOR LIGHTS SYSTEM (I/P LAMPS DIMMER SWITCH)
M/T
ORG/ WIRE
OTHERS
PARK/ NEUTRAL POSITION AND BACKUP LAMPS SWITCH
PNK (ENGINE HARNESS, APPROX 26 CM FROM BULKHEAD GROMMET) WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (ELEC)
SEAT BELTS ALARM MODULE
TORQUE CONVERTER CLUTCH, STOP LAMPS SWITCH
TURN B/U FUSE 5
TURN SIGNAL FLASHER
VEHICLE CONTROL MODULE (VCM)
WATER IN FUEL INDICATOR SENSOR FUEL HEATER GLOW PLUG CONTROLLER (CALIF)
Go to component -> Power distribution circuit, commercial chassis (4 of 4) -> DAYTIME RUNNING LAMP RELAY INSTRUMENT CLUSTER
