Chevrolet Forward Control P30 (1985-1999) aux fan sw signal Wiring diagram
This page shows the only wiring diagram for the component.aux fan sw signal, which is found in the car Chevrolet Forward Control P30 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aux fan sw signal (1 of 1)
AUX FAN CTRL
AUX FAN SW SIGNAL
BLK WIRE
BLU WIRE
DK BLU WIRE
ENG BAT FUSE 10
ENGINE COOLANT FAN MOTOR (MOUNTED TO RADIATOR)
FAN CONTROL RELAY (ON TOP OF STEERING COLUMN SUPPORT, BEHIND STEERING COLUMN)
FUSIBLE LINK (18 GA-
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND DASH PANEL)
ORG/ WIRE
RED WIRE
VEHICLE CONTROL MODULE (VCM) (ON TOP OF RADIATOR SUPPORT)
Go to component -> 7.4l (vin j), cooling fan circuit -> AUX FAN SW SIGNAL
