Chevrolet Forward Control P30 (1985-1999) a/t output speed sensor shield Wiring diagram
This page shows the only wiring diagram for the component.a/t output speed sensor shield, which is found in the car Chevrolet Forward Control P30 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t output speed sensor shield (1 of 1)
6.5L
7.4L
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH
A/T OUTPUT SPEED SENSOR SHIELD
BATTERY
BLK WIRE
BRAIDED STRAP
DAYTIME RUNNING LAMP RELAY 2
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE
ENGINE BLOCK)
FUEL HEATER (6.5L)
FUEL PUMP RELAY
GLOWPLUG CONTROLLER (6.5L CALIFORNIA)
GLOWPLUG CONTROLLER (6.5L FEDERAL)
HIGH NOTE HORN
IGNITION CONTROL MODULE
LEFT HEADLAMP RIGHT HEADLAMP
LEFT INNER HEADLAMP LOW NOTE HORN
LEFT OUTER HEADLAMP
LOW NOTE HORN
MASS AIR FLOW SENSOR
PARK/ NEUTRAL POSITION SWITCH RELAY
POWERTRAIN CONTROL MODULE
RIGHT INNER HEADLAMP
RIGHT OUTER HEADLAMP
SECONDARY BATTERY (DIESEL ONLY)
STARTER RELAY
STOP LAMP RESISTOR
VEHICLE CONTROL MODULE
W/ DUAL HEADLIGHTS
W/O DRL
W/O DUAL HEADLIGHTS
WATER IN FUEL INDICATOR SENSOR (6.5L)
WHT WIRE
Go to component -> Ground distribution circuit, motor home chassis (1 of 2) -> A/T OUTPUT SPEED SENSOR SHIELD
