Chevrolet Forward Control P30 (1985-1999) a/c enable Wiring diagrams
This page contains all the electrical diagrams for the component. a/c enable, in which he is found in the car Chevrolet Forward Control P30 (1985-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
a/c enable wiring diagram (1 of 8)
A/C COMPRESSOR CLUTCH RELAY (ENGINE BULKHEAD RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (REAR OF COMPRESSOR)
A/C ENABLE
BLK WIRE
DIODE A/C COMPRESSOR CLUTCH
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BOX
ORG/ WIRE
PNK WIRE
VEHICLE CONTROL MODULE (LEFT RADIATOR SUPPORT) A/C REQUEST
WHT WIRE
Go to component -> 4.3l (vin w), a/c circuit -> A/C ENABLE
a/c enable wiring diagram (2 of 8)
A/C COMPRESSOR CLUTCH RELAY (ENGINE FIREWALL RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF A/C COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (A/C ACCUMULATOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (ON A/C ACCUMULATOR)
A/C ENABLE
A/C GROUND
BLK WIRE
DIODE A/C COMPRESSOR CLUTCH
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK
LT BLU WIRE
ORG/ WIRE
PNK WIRE
VEHICLE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) A/C REQUEST
WHT WIRE
Go to component -> 4.3l (vin w), air conditioning circuits -> A/C ENABLE
a/c enable wiring diagram (3 of 8)
A/C COMPRESSOR CLUTCH RELAY (ENGINE BULKHEAD RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (REAR OF COMPRESSOR)
A/C ENABLE
BLK WIRE
DIODE A/C COMPRESSOR CLUTCH
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BOX
ORG/ WIRE
PNK WIRE
VEHICLE CONTROL MODULE (LEFT RADIATOR SUPPORT) A/C REQUEST
WHT WIRE
Go to component -> 5.7l (vin r), a/c circuit -> A/C ENABLE
a/c enable wiring diagram (4 of 8)
A/C COMPRESSOR CLUTCH RELAY (ENGINE FIREWALL RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF A/C COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (A/C ACCUMULATOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (ON A/C ACCUMULATOR)
A/C ENABLE
A/C GROUND
BLK WIRE
DIODE A/C COMPRESSOR CLUTCH
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK
LT BLU WIRE
ORG/ WIRE
PNK WIRE
VEHICLE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) A/C REQUEST
WHT WIRE
Go to component -> 5.7l (vin r), air conditioning circuits -> A/C ENABLE
a/c enable wiring diagram (5 of 8)
A/C COMPRESSOR CLUTCH DIODE
A/C COMPRESSOR CLUTCH RELAY (ENGINE BULKHEAD RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (REAR OF COMPRESSOR)
A/C ENABLE
AUXILIARY ENGINE COOLANT FAN
AUXILIARY ENGINE COOLANT FAN A/C PRESSURE SWITCH (IN A/C HIGH PRESSURE LINE)
AUXILIARY ENGINE COOLANT FAN RELAY (ENGINE BULKHEAD RELAY BRACKET)
AUXILIARY FAN CONTROL SWITCH (ON RIGHT SIDE OF CYLINDER HEAD)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG 1 FUSE
ENG-BAT FUSE
FUSIBLE LINK
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
I/P FUSE BOX
ORG/ WIRE
PNK WIRE
RED WIRE
VIN J VIN F
WHT WIRE
Go to component -> 6.5l (vin f), a/c circuit -> A/C ENABLE
a/c enable wiring diagram (6 of 8)
A/C COMPRESSOR CONTROL RELAY (RIGHT SIDE OF DRIVER'S ISLAND)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (IN HIGH PRESSURE LINE)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (REAR OF A/C COMPRESSOR)
A/C ENABLE
BLK WIRE
BRN WIRE
DIODE A/C COMPRESSOR CLUTCH
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF DRIVER'S ISLAND) A/C REQUEST
WHT WIRE
Go to component -> 6.5l (vin f), air conditioning circuits -> A/C ENABLE
a/c enable wiring diagram (7 of 8)
A/C COMPRESSOR CLUTCH DIODE
A/C COMPRESSOR CLUTCH RELAY (ENGINE BULKHEAD RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (REAR OF COMPRESSOR)
A/C ENABLE
AUXILIARY ENGINE COOLANT FAN
AUXILIARY ENGINE COOLANT FAN A/C PRESSURE SWITCH (IN A/C HIGH PRESSURE LINE)
AUXILIARY ENGINE COOLANT FAN RELAY (ENGINE BULKHEAD RELAY BRACKET)
AUXILIARY FAN CONTROL SWITCH (ON RIGHT SIDE OF CYLINDER HEAD)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG 1 FUSE
ENG-BAT FUSE
FUSIBLE LINK
GAUGES FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
I/P FUSE BOX
ORG/ WIRE
PNK WIRE
RED WIRE
VIN J VIN F
WHT WIRE
Go to component -> 7.4l (vin j), a/c circuit -> A/C ENABLE
a/c enable wiring diagram (8 of 8)
A/C COMPRESSOR CLUTCH RELAY (RIGHT SIDE OF DRIVER'S ISLAND)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF A/C COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (A/C ACCUMULATOR)
A/C ENABLE
A/C GROUND
A/C REQUEST
BLK WIRE
BRN WIRE
DIODE A/C COMPRESSOR CLUTCH
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
GAUGES FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK
ORG/ WIRE
PNK WIRE
VEHICLE CONTROL MODULE (CENTER FRONT OF ENGINE COMPT)
WHT WIRE
Go to component -> 7.4l (vin j), air conditioning circuits -> A/C ENABLE
