Chevrolet Express G3500 (2013-2013) lpg primary control fuel level module sensor Wiring diagram
This page shows the only wiring diagram for the component.lpg primary control fuel level module sensor, which is found in the car Chevrolet Express G3500 (2013-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lpg primary control fuel level module sensor (1 of 1)
4.8L/5.3L/6.0L
AT GROUND TO LPG BYPASS SOLENOID) W/ 3 TANK VEHICLE KIT, LPG
AUXILIARY BATTERY
BATTERY
BATTERY CURRENT SENSOR (EXCEPT 6.6L)
BLK WIRE
BLK/WHT WIRE
CM FROM
CONNECTOR
EXHAUST GAS RECIRCULATION VALVE SHIELD
FUEL
FUEL INJECTOR CONTROL MODULE
GROUND TO LPG CONTROL MODULE, WAIT TO START LAMP)
HARNESS, 7.5 CM FROM PRIMARY FUEL LEVEL SENSOR)
IGNITION (EV) RELAY RELAY RELAY WIPER WIPER HI DIODE DIODE
IGNITION IGNITION COIL 1 COIL 8
IGNITION IGNITION COIL 3 COIL 5
IGNITION IGNITION IGNITION COIL 4 COIL 6 COIL 2
INDICATOR
LEFT FRONT MARKER LAMP
LEFT PARK/TURN SIGNAL LAMP
LPG BYPASS SOLENOID VALVE
LPG CONTROL MODULE
LPG PRIMARY CONTROL FUEL LEVEL MODULE SENSOR
NCA WIRE
RUN WIRE
RUN/ CRNK RELAY
SECONDARY FUEL LEVEL SENSOR
UNDERHOOD FUSE BLOCK CRNK PUMP (ON LEFT LAMP RELAY RELAY SIDE OF ENGINE COMPT)
W/ 4 TANK COMPLETE VEHICLE KIT
WAIT TO
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
Go to component -> Ground distribution circuit (1 of 5) -> LPG PRIMARY CONTROL FUEL LEVEL MODULE SENSOR
