Chevrolet Express G3500 (2013-2013) 2 59 28 60 serial data lh seat belt sw low ref rh seat belt sw Wiring diagram

19 15 16 ALARM ENABLE SIG HAZARD SW LEFT SIG HAZARD SW RIGHT SIG 2 59 28 60 SERIAL DATA LH SEAT BELT SW LOW REF RH SEAT BELT SW 8 17 PARK LAMP SIGNAL HEADLAMP SW OFF SIG AIR BAG FUSE AUTO OFF 3 8 BATTERY BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH) BODY FUSE BLOCK (UNDER LEFT FRONT SEAT) BRAKE FLUID LEVEL SWITCH BRAKE PRESSURE DIFFERENTIAL SWITCH CHIME MODULE (W/O RADIO) (BEHIND LEFT CENTER OF DASH) COMPUTER DATA LINES SYSTEM CONNECTOR BREAKOUT) DK BLU/WHT WIRE DK GRN WIRE DRIVER DOOR LATCH ASSEMBLY (AT REAR OF DRIVER DOOR) DRIVER INFORMATION CENTER (DIC) DISPLAY DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT SWITCH FUSE GROUND GRY WIRE GRY/BLK WIRE HAZARD SWITCH HAZARD WARNING SWITCH HEAD PARK HEADLAMP, PANEL DIMMER SWITCH HOT AT ALL TIMES IGN SW IGNITION KEY SWITCH IGNITION SWITCH INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER LEFT FRONT SEAT) INSTRUMENT PANEL CLUSTER (IPC) LEFT REAR DOOR JAMB SWITCH (W/ LEFT REAR HINGED DOOR) (AT LEFT "B" PILLAR) LEFT TURN LIGHT PPL DUTY LOGIC LT BLU WIRE LT BLU/BLK WIRE OFF ORG/ WIRE PARK BRAKE SWITCH PARK BRK SW SIG PASSENGER DOOR LATCH ASSEMBLY (AT REAR OF FRONT PASSENGER DOOR) PASSENGER SEAT BELT BUCKLE (W/O MANUAL SUPPRESSION SWITCH, RV UPFITTER) PASSENGER SEAT BELT SWITCH PNK IGN VOLT WIRE PNK PNK PNK PNK WIRE PNK PNK WIRE PNK WIRE PPL PPL HEAVY DUTY PPL PNK WIRE PPL PPL SENS SIG RADIO RDO/CHIME FUSE RED WIRE RED/WHT WIRE RIGHT REAR DOOR JAMB SWITCH (CARGO/ PASSENGER) (AT RIGHT "B" PILLAR) RIGHT TURN RUN WIRE SEAT BELT IND LOW OIL PRESSURE IND TIRE PRESSURE IND SERIAL DATA SPLICE BLOCK TAN WIRE TAN/WHT WIRE W/ ELECTRIC SIDE DOOR LOCK CONTROL W/ MANUAL SUPPRESSION SWITCH W/O MANUAL SUPPRESSION SWITCH, RV UPFITTER WHT WIRE YEL WIRE YEL/BLK WIRE
