Chevrolet Express G2500 (2013-2013) passenger window passenger outside switch rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.passenger window passenger outside switch rearview mirror, which is found in the car Chevrolet Express G2500 (2013-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger window passenger outside switch rearview mirror (1 of 1)
AUXILIARY HVAC CONTROL MODULE
BLK WIRE
CUTAWAY UPFITTER
DOME LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER WINDOW SWITCH
FRONT AUXILIARY HVAC CONTROL ASSEMBLY
FRONT DOME/ READING LAMPS
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER DOOR LOCK SWITCH
PASSENGER WINDOW PASSENGER OUTSIDE SWITCH REARVIEW MIRROR
REAR AUXILIARY HVAC CONTROL ASSEMBLY
RIGHT LEFT SUNSHADE SUNSHADE
RIGHT LEFT VANITY VANITY MIRROR MIRROR LAMP LAMP
RV UPFITTER
RV UPFITTER (NOT USED)
SPLICE BLOCK
W/ ELECTRIC SIDE DOOR LOCK CONTROL
W/ POWER MIRRORS, WINDOWS
W/ REAR A/C W/O RV UPFITTER
W/ REAR A/C, RV UPFITTER
W/ REAR A/C, RV UPFITTER, SWB PASSENGER
W/O ELECTRIC SIDE DOOR LOCK CONTROL
W/O POWER MIRRORS, WINDOWS
W/O REAR A/C, FRONT VANITY MIRROR W/ CUTAWAY UPFITTER
Go to component -> Ground distribution circuit (4 of 5) -> PASSENGER WINDOW PASSENGER OUTSIDE SWITCH REARVIEW MIRROR
