Starting circuit, w/o stop/start system for Chevrolet Equinox III facelift (2020-2024)

BATTERY BATTERY FUSE BLOCK BATTERY SENSOR MODULE BLK WIRE BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BELOW CENTER OF DASH) COMPUTER DATA LINES SYSTEM GENERATOR GMLAN SER DATA - (1) IGN MODE SW VOLT IGNITION MODE SWITCH LOGIC RED WIRE STARTER MOTOR STARTER RELAY UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE YEL/VIO WIRE

AUTOMATIC TRANSMISSION ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY (6 SPEED A/T) BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) GMLAN SER DATA - (1) GRN/YEL WIRE HOT W/ IGNITION MAIN RELAY ENERGIZED IGN 1 VOLT IMS CTRL BACKUP IMS MODE SW LO CTRL IMS MODE SW LOW REF NCA WIRE RUN/CRANK IGN 1 VOLT SIG GND STARTER PINION SOL RLY CTRL TRANS PARK/ NEUTRAL SIG 1 TRANS PARK/NEUTRAL SIG 1 TRANSMISSION CONTROL MODULE TRANSMISSION CONTROL MODULE (9 SPEED A/T) (LEFT SIDE OF TRANSMISSION) TRANSMISSION INTERNAL MODE SWITCH UNDERHOOD FUSE BLOCK VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/GRY WIRE YEL/BLU WIRE YEL/VIO WIRE
