Chevrolet Equinox III facelift (2020-2024) w/o retractable head-up display w/ retractable head-up display Wiring diagrams
This page contains all the electrical diagrams for the component. w/o retractable head-up display w/ retractable head-up display, in which he is found in the car Chevrolet Equinox III facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o retractable head-up display w/ retractable head-up display (1 of 2)
AMBIENT LIGHT SENSOR SIG
AMBIENT LIGHT/ SUNLOAD SENSOR
AUTO
AUTOMATIC HIGH BEAM ON/OFF SW SIG
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT FOG LAMP CTRL
FRONT FOG LAMP SWITCH
FT FOG LAMP SW SIG
GRN/BRN WIRE
GRN/GRY WIRE
GROUND
GRY/BLU WIRE
HDLP SW FLASH
HDLP SW OFF SIG
HDLP SW ON SIG
HDLP SW PARK LAMP SIG
HEAD
HEADLAMP SWITCH
HI BEAM SELECT SW HI BEAM SIG
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HVAC CONTROL MODULE (TOP CENTER OF DASH)
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT DRL CTRL
LEFT FRONT FOG LAMP
LEFT HEADLAMP RLY CTRL
LEFT LOW BEAM SPLY CTRL
LOW REF
OFF
PARK
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP LOW BEAM CTRL
RIGHT HEADLAMP RLY CTRL
RIGHT PARK LAMP CTRL
TURN SIGNAL/ MULTI-FUNCTION SWITCH
VIO WIRE
VIO/GRY WIRE
W/O RETRACTABLE HEAD-UP DISPLAY W/ RETRACTABLE HEAD-UP DISPLAY
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> Headlights circuit, w/ drl (1 of 3) -> W/O RETRACTABLE HEAD-UP DISPLAY W/ RETRACTABLE HEAD-UP DISPLAY
Wiring diagram w/o retractable head-up display w/ retractable head-up display (2 of 2)
AMBIENT LIGHT SENSOR SIG
AMBIENT LIGHT/ SUNLOAD SENSOR
AUTO
AUTOMATIC HIGH BEAM ON/OFF SW SIG
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT FOG LAMP CTRL
FRONT FOG LAMP SWITCH
FT FOG LAMP SW SIG
GRN/BRN WIRE
GRN/GRY WIRE
GROUND
GRY/BLU WIRE
HDLP SW FLASH
HDLP SW OFF SIG
HDLP SW ON SIG
HDLP SW PARK LAMP SIG
HEAD
HEADLAMP SWITCH
HI BEAM SELECT SW HI BEAM SIG
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HVAC CONTROL MODULE (TOP CENTER OF DASH)
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT DRL CTRL
LEFT HEADLAMP RLY CTRL
LEFT LOW BEAM SPLY CTRL
LOW REF
OFF
PARK
RED/BLU WIRE
RED/GRN WIRE
RIGHT HEADLAMP LOW BEAM CTRL
RIGHT HEADLAMP RLY CTRL
RIGHT PARK LAMP CTRL
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/O RETRACTABLE HEAD-UP DISPLAY W/ RETRACTABLE HEAD-UP DISPLAY
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> Headlights circuit, w/o drl (1 of 3) -> W/O RETRACTABLE HEAD-UP DISPLAY W/ RETRACTABLE HEAD-UP DISPLAY
