Chevrolet Equinox III facelift (2020-2024) transmission shift pos indicator 2 control shift select sw performance sig Wiring diagram
This page shows the only wiring diagram for the component.transmission shift pos indicator 2 control shift select sw performance sig, which is found in the car Chevrolet Equinox III facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission shift pos indicator 2 control shift select sw performance sig (1 of 1)
BATT POS VOLT
BATTERY FUSE BLOCK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
BUS 2
COIL CTRL
COMPUTER DATA LINES SYSTEM
DRIVE MODE SELECT SWITCH
GRN/BLU WIRE
GRY/VIO WIRE
HI SPD GMLAN SER DATA -
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LOGIC
NETWORK
NETWORK BUS 2
PARK LOCK SOL CTRL
PARK POSITION SWITCH
POWER SUPPLY TRANSFORMER
PRESS BRAKE
RAP RLY
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
SHIFT POS SIG
SIG GND
SPLY
TAP UP/TAP DOWN SW SIG
TOW/HAUL SWITCH
TRANSMISSION RANGE SELECTOR CONTROLS
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
TRANSMISSION SHIFT POS INDICATOR 2 CONTROL SHIFT SELECT SW PERFORMANCE SIG
UNDERHOOD FUSE BLOCK
UP/DOWN TRANSMISSION MANUAL SHIFT SWITCH
VIO/BLK WIRE
VIO/GRN WIRE
VIO/YEL WIRE
VOLT 2
WHT WIRE
WHT/VIO WIRE
Go to component -> A/t circuit, 9 speed (4 of 4) -> TRANSMISSION SHIFT POS INDICATOR 2 CONTROL SHIFT SELECT SW PERFORMANCE SIG
