Chevrolet Equinox III facelift (2020-2024) transmission shift lever position indicator 2 control Wiring diagram
This page shows the only wiring diagram for the component.transmission shift lever position indicator 2 control, which is found in the car Chevrolet Equinox III facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission shift lever position indicator 2 control (1 of 1)
BATT POS VOLT
BATTERY FUSE BLOCK
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
CTRL
DRIVER MODE SELECT SWITCH
GRN/BLU WIRE
GRN/VIO WIRE
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LOGIC
NETWORK BUS 2
PARK LOCK SOL CTRL
PARK POSITION SWITCH
POWER SUPPLY TRANSFORMER
PRESS BRAKE
RAP RLY COIL
RED/GRN WIRE
RED/GRY WIRE
SHIFT POS SIG
SHIFT SELECT SWITCH PERFORMANCE SIG
SPLY VOLT 2
TAP UP/TAP DOWN SW SIG
TOW/HAUL SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LEVER POSITION INDICATOR 2 CONTROL
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
UNDERHOOD FUSE BLOCK
UP/DOWN TRANSMISSION MANUAL SHIFT SWITCH
VIO/BLK WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/VIO WIRE
Go to component -> A/t circuit, 6 speed (2 of 3) -> TRANSMISSION SHIFT LEVER POSITION INDICATOR 2 CONTROL
