Chevrolet Equinox III facelift (2020-2024) liftgate close switch led control Wiring diagram
This page shows the only wiring diagram for the component.liftgate close switch led control, which is found in the car Chevrolet Equinox III facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate close switch led control (1 of 1)
BLK WIRE
CENTER CONSOLE COMPARTMENT LAMP
CENTER CONSOLE CUPHOLDER ACCENT LAMP
COMPUTER DATA LINES SYSTEM
DRIVER DOOR ACCENT LAMP
DRIVER DOOR HANDLE ACCENT LAMP
FRONT OVERHEAD CONSOLE ASSEMBLY
GRN/BRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
LEFT REAR DOME/ READING LAMPS
LIFTGATE CLOSE SWITCH
LIFTGATE CLOSE SWITCH LED CONTROL
LIFTGATE CONTROL MODULE
LIFTGATE CONTROL MODULE LIN BUS 1
NCA WIRE
PASSENGER DOOR ACCENT LAMP
PASSENGER DOOR HANDLE ACCENT LAMP
RIGHT INSTRUMENT PANEL ACCENT LAMP
RIGHT REAR DOME/ READING LAMPS
W/ INTERIOR LAMP PACKAGE
WHT/BRN WIRE
WHT/YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LIFTGATE CLOSE SWITCH LED CONTROL
