Chevrolet Equinox III (2017-2021) w/o electronic transmission range selector system, start/stop Wiring diagram
This page shows the only wiring diagram for the component.w/o electronic transmission range selector system, start/stop, which is found in the car Chevrolet Equinox III (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o electronic transmission range selector system, start/stop (1 of 1)
6 SPEED A/T
ACCY WAKEUP SER DATA
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/YEL WIRE
EXHAUST PARTICULATE MATTER SENSOR
FUEL PUMP DRIVER CONTROL MODULE
GRN WIRE
GRN/PPL WIRE
HI SPD GMLAN
HI SPD GMLAN SER DATA (+) 1
HI SPD GMLAN SER DATA (+) 3
HI SPD GMLAN SER DATA (-) 7
NETWORK SER DATA BUS 21
NITROGEN OXIDES SENSOR 1 (IN TURBOCHARGER OUTLET)
PPL/YEL WIRE
REDUCTANT CONTROL MODULE
SER DATA (-) 7
W/ START/STOP W/O START/STOP
W/O CATALYTIC REDUCTION SYSTEM
W/O ELECTRONIC TRANSMISSION RANGE SELECTOR SYSTEM, START/STOP
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit (5 of 8) -> W/O ELECTRONIC TRANSMISSION RANGE SELECTOR SYSTEM, START/STOP
