Chevrolet Equinox III (2017-2021) right outside rearview mirror wiring diagram
This page shows the only wiring diagram for the component.right outside rearview mirror, which is found in the car Chevrolet Equinox III (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right outside rearview mirror wiring diagram (1 of 1)
1-BG
1-RD
2-BG
2-RD
BATT POS VOLT
BLK WIRE
CAM FUSE
COAX
COMPUTER DATA LINES SYSTEM
GRILLE FRONTVIEW CAMERA
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT OUTSIDE REARVIEW MIRROR
LEFT SIDEVIEW CAMERA
LOW SPD GMLAN SERIAL DATA 2
OG CAMERA VIDEO SIG
RADIO
REAR BODY FUSE BLOCK
REARVIEW CAMERA
RED/WHT WIRE
RIGHT OUTSIDE REARVIEW MIRROR
RIGHT SIDEVIEW CAMERA
VIDEO PROCESSING CONTROL MODULE
Go to component -> All around vision camera circuit -> RIGHT OUTSIDE REARVIEW MIRROR
