Chevrolet Equinox II facelift (2015-2017) sw close vent sig local interconnect network 1 Wiring diagram
This page shows the only wiring diagram for the component.sw close vent sig local interconnect network 1, which is found in the car Chevrolet Equinox II facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sw close vent sig local interconnect network 1 (1 of 1)
BLK WIRE
CLOSE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
EXPRESS
HOT AT ALL TIMES
LOGIC
LT BLU WIRE
ORG/BLK WIRE
PNK SW DAT 1 WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
S/ROOF FUSE
SUNROOF MOTOR (BEHIND SUNROOF)
SUNROOF SWITCH
SUNROOF TILT SWITCH
SW CLOSE VENT SIG LOCAL INTERCONNECT NETWORK 1
SW LOW REF PPL SW OPEN VENT SIG
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> Power top/sunroof circuit -> SW CLOSE VENT SIG LOCAL INTERCONNECT NETWORK 1
