Chevrolet Equinox II facelift (2015-2017) serial data low local interconnect network 10 Wiring diagram

BLK WIRE BLK/WHT WIRE DATA LINK CONNECTOR (LOWER LEFT SIDE DASH) DK BLU WIRE DK GRN WIRE DLC FUSE DRIVER MIRROR CONTROL MODULE FRONT VIEW CAMERA MODULE GRY WIRE HOT AT ALL TIMES HVAC CONTROL MODULE (BEHIND HVAC, RADIO CONTROLS) INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE INFO DISPLAY MODULE INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LEFT REAR WINDOW SWITCH LEFT SIDE OBJECT SENSOR MODULE (IF EQUIPPED) (BEHIND LEFT END OF REAR BUMPER) LO SPD GMLAN SER DATA LOCAL INTERCONNECT LOCAL INTERCONNECT NETWORK 10 LOCAL INTERCONNECT NETWORK 2 LOCAL INTERCONNECT NETWORK 8 LOCAL INTERCONNECT NETWORK 9 LOCAL INTERCONNECT NETWORK 9 LOW SPEED GMLAN SERIAL DATA LOW SPEED GMLAN SERIAL DATA LT BLU WIRE MULTIMEDIA PLAYER INTERFACE MODULE (W/ AUDIO INTERFACE) NCA WIRE NETWORK 4 PASSENGER PRESENCE MODULE (BELOW PASSENGER'S SEAT CUSHION) RADIO RADIO/HVAC CONTROLS REAR PARKING ASSIST CONTROL MODULE (IF EQUIPPED) RED WIRE RED/WHT WIRE RIGHT REAR WINDOW SWITCH RIGHT SIDE OBJECT SENSOR MODULE (IF EQUIPPED) (BEHIND RIGHT END OF REAR BUMPER) SEAT HEATING CONTROL MODULE (IF EQUIPPED) (UNDER DRIVER'S SEAT) SEAT MEMORY CONTROL MODULE (W/ MEMORY) (UNDER DRIVER'S SEAT) SERIAL DATA HI SERIAL DATA LOW SERIAL DATA LOW LOCAL INTERCONNECT NETWORK 10 SERIAL DATA SHEILD SERIAL DATA HI SERIAL DATA SHIELD TAN WIRE TAN/BLK WIRE TRANSMISSION SHIFT LEVER POSITION INDICATOR W/ NAVIGATION W/ PREMIUM 8 SPEAKER SYSTEM W/O NAVIGATION WHT WIRE YEL WIRE
