Chevrolet Equinox II facelift (2015-2017) rf discriminating sensor sig Wiring diagram
This page shows the only wiring diagram for the component.rf discriminating sensor sig, which is found in the car Chevrolet Equinox II facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf discriminating sensor sig (1 of 1)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER SEAT BELT ANCHOR -
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT RETRACTOR
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SEAT BELT SWITCH
DRV SEAT BELT SW
DRV SEAT BELT SW LOW REF
GRY WIRE
GRY/BLK WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
LEFT FRONT SEAT SIDE AIR BAG
LEFT FRONT SIDE IMPACT SENSOR
LEFT REAR SIDE IMPACT SENSOR
LEFT ROOF RAIL AIR BAG
LEFT ROOF RAIL MOD HIGH
LEFT ROOF RAIL MOD LOW
LF DISCRIMINATING SENSOR SIG
LH MIDDLE SIDE SENSING LOW REF
LH SIDE AIR BAG -
LH SIDE IMPACT SENSING MOD
LOW REF
LOW REF RH MIDDLE SIDE SENSING
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
ORG/ WIRE
PASS SEAT BELT ANCHOR
PASS SEAT BELT RETRACTOR
PASS SEAT BELT SW LOW REF
PASS SEAT BELT SW SIG
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SEAT BELT SWITCH
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RF DISCRIMINATING SENSOR SIG
RH ROOF RAIL MOD HIGH CTRL
RH ROOF RAIL MOD LOW CTRL
RH SIDE AIR BAG +
RH SIDE IMPACT SENSING MOD
RIGHT FRONT SEAT SIDE AIR BAG
RIGHT REAR SIDE IMPACT SENSOR
RIGHT ROOF RAIL AIR BAG
SHORTING BAR
TAN/BLK WIRE
TAN/ORG WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> RF DISCRIMINATING SENSOR SIG
