Chevrolet Equinox II facelift (2015-2017) ign lock sol ctrl Wiring diagram
This page shows the only wiring diagram for the component.ign lock sol ctrl, which is found in the car Chevrolet Equinox II facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign lock sol ctrl (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DLIS FUSE
ENGINE CONTROL MODULE
GRY WIRE
HOT AT ALL TIMES
IGN LOCK SOL CTRL
IGNITION CYLINDER LOCK CONTROL SWITCH
IGNITION SWITCH
INSTRUMENT PANEL FUSE BLOCK
KEY CAPTURE SOLENOID ACTUATOR
KEY CAPTURE/ COLUMN LOCK SHIFT POS SIG
KEY-IN IGNITION SWITCH
LOW REF
OFF
PNK IGN VOLT WIRE
PNK WIRE
PPL/WHT WIRE
RED/WHT WIRE
RUN WIRE
RVC BATT SNSR FUSE
SENS SIG
SER DATA BUS -
TAN WIRE
TAN/BLK WIRE
TRANSMISSION SHIFT LEVER
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Ignition lock solenoid circuit -> IGN LOCK SOL CTRL
