Chevrolet Equinox II facelift (2015-2017) endgate latch relay ctrl wiring diagram
This page shows the only wiring diagram for the component.endgate latch relay ctrl, which is found in the car Chevrolet Equinox II facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
endgate latch relay ctrl wiring diagram (1 of 1)
BCM 1 FUSE
BLK WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ENDGATE LATCH RELAY COIL CTRL
ENDGATE LATCH RELAY CTRL
GMLAN SERIAL DATA
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LIFTGATE AJAR SWITCH SIGNAL 1
LIFTGATE HANDLE SWITCH
LIFTGATE LATCH ASSEMBLY
LIFTGATE UNLATCH RELAY
LOGIC
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
PNK/BLK WIRE
REAR CLOSURE FUSE
REAR CLOSURE HANDLE SWITCH OPEN SIGNAL
RED/WHT WIRE
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> Liftgate release circuit -> ENDGATE LATCH RELAY CTRL
