Chevrolet Equinox II facelift (2015-2017) cooling fan low speed relay control Wiring diagram
This page shows the only wiring diagram for the component.cooling fan low speed relay control, which is found in the car Chevrolet Equinox II facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooling fan low speed relay control (1 of 1)
2.4L
2.4L 3.6L
3.6L
A/C COMPRESSOR CLUTCH RELAY
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BRAKE BOOSTER MOTOR PUMP RELAY
CONTROL SOLENOID VALVE ASSEMBLY
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY CONTROL
COOLING FAN SPEED CONTROL RELAY
ECM FUSE
ENGINE CONTROL MODULE
ENGINE CONTROLS IGNITION RELAY
EVAPORATIVE EMISSION PURGE SOLENOID VALVE
EVEN IGN FUSE
FROM BODY CONTROL MODULE (DIAGRAM 2 OF 4)
FROM I/P BEC 3 FUSE (DIAGRAM 2 OF 4)
FSCM FUSE
FUEL PUMP DRIVER CONTROL MODULE
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 2
HEATED OXYGEN SENSOR BANK 1 SENSOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 1
HEATED OXYGEN SENSOR BANK 2 SENSOR 2
I/P BEC FUSE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION MAIN RELAY
INSIDE REAR VIEW MIRROR
MIR FUSE
MULTI-FUNCTION INTAKE AIR SENSOR
NCA WIRE
ODD IGN FUSE
PASSENGER AIR BAG DISABLE INDICATOR
PNK WIRE
PNK/BLK WIRE
REAR CAM FUSE
REAR VIEW CAMERA
SECONDARY AIR INJECTION PUMP RELAY
SECONDARY AIR INJECTION SOLENOID VALVE RELAY
TCM FUSE
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 3 OF 4)
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> COOLING FAN LOW SPEED RELAY CONTROL
