2.4l vin k, rear differential lock circuit for Chevrolet Equinox II (2009-2015)
2.4l vin k, rear differential lock circuit
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
GMLAN DATA BUS+ GMLAN DATA BUS+ GMLAN DATA BUS-
HOT AT ALL TIMES
LT BLU WIRE
RDM FUSE (LEFT REAR OF ENGINE COMPT)
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR DRIVE CLUTCH
REAR DRIVE MTR CTRL SLIP DIF VALVE CTRL REAR DRIVE MTR CTRL SLIP DIF VALVE CTRL
RED/BLK WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK
