Chevrolet Equinox II (2009-2015) Ignition lock solenoid circuit

BATT POS VOLT BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF DASH) DLIS FUSE IGNITION CYLINDER LOCK CONTROL SWITCH KEY CAPTURE SOLENOID ACTUATOR (NEXT TO IGNITION SWITCH) KEY IN IGNITION SWITCH IGNITION SWITCH LOW REF OFF PNK IGN VOLT WIRE PNK WIRE PPL/WHT WIRE RED/WHT WIRE RUN WIRE RVC BATT SNSR FUSE TAN WIRE TAN/BLK WIRE TRANSMISSION SHIFT LEVER UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT) WHT WIRE YEL WIRE
