Passenger power seat circuit for Chevrolet Equinox II (2009-2015)
Passenger power seat circuit
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DOWN UP
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT FRONT VERTICAL MOTOR
PASSENGER SEAT HORIZONTAL MOTOR
PASSENGER SEAT LUMBAR SUPPORT
PASSENGER SEAT LUMBAR SUPPORT HORIZONTAL MOTOR
PASSENGER SEAT REAR VERTICAL MOTOR
PASSENGER SEAT RECLINE MOTOR
PWR LUMBAR RT FUSE
PWR SEAT RT FUSE
RED/WHT WIRE
RWD
RWD FWD
SWITCH
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
UP DOWN
WHT WIRE
YEL WIRE
