Heated seats circuit, without spo heated seats & memory for Chevrolet Equinox II (2009-2015)
Heated seats circuit, without spo heated seats & memory
5 6 7 8 9 10 11 12 13 14 15 16 SUPPLY VOLT
BATT POS VOLT
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER BACK HEATING SEAT
DRIVER CUSHION HEATING SEAT ELEMENT
DRIVER HEATED SEAT SWITCH
ELEMENT
GMLAN SERIAL DATA
GROUND
GRY WIRE
HIGH HEAT IND
HOT AT ALL TIMES
HTD/ SEAT FRT FUSE
INFO DISPLAY MODULE
LOGIC
LOW HEAT IND
LOW REF LOW REF PNK WIRE
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT GRN WIRE
MEDIUM HEAT IND
NCA WIRE
PASSENGER BACK HEATING SEAT
PASSENGER CUSHION HEATING SEAT ELEMENT
PASSENGER HEATED SEAT SWITCH
PNK WIRE
PPL
RED WIRE
RED/WHT WIRE
SEAT HEATING CONTROL MODULE (UNDER DRIVER'S SEAT)
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
