Driver power seat circuit for Chevrolet Equinox II (2009-2015)
Driver power seat circuit
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DOWN
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
DRIVER SEAT RECLINE MOTOR
DRIVER SEAT VERTICAL MOTOR
FWD DN
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PPL
PWR SEAT LT FUSE
RED/WHT WIRE
RWD RWD
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
UP DN
W/ 8 WAY ADJUSTER FRONT SEAT POWER, MEMORY
W/O 8 WAY ADJUSTER FRONT SEAT POWER, MEMORY
YEL WIRE
