Electrochromic mirror circuit, without rear view camera for Chevrolet Equinox II (2009-2015)
Electrochromic mirror circuit, without rear view camera
1 2 3 4 5 6 7 8 9 10 PNK WIRE
11 6 KEY SIGNAL KEY SPLY VOLT
3 2 GREEN LED SIG
BACKUP SPLY
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BREAKOUT)
BRN/WHT WIRE
COMP SW
DISPLAY
DK GRN/WHT WIRE
EMERGENCY IND
EMERGENCY SWITCH
GREEN LED
GROUND BACKUP LMP SPLY VOLT
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN
INSIDE REARVIEW MIRROR
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MIR FUSE
MIRROR DIMMING
ONSTAR IND
ONSTAR SWITCH
PHONE IND
PHONE SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED LED SIG WIRE
RED LED WIRE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (W/ ONSTAR) (CENTER OF DASH)
TEMP SW
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
YEL/BLK WIRE
