Electronic power steering circuit for Chevrolet Equinox II (2009-2015)
Electronic power steering circuit
1 2 GROUND BATT POS VOLT
2.4L
3.0L
ANTI-LOCK BRAKES SYSTEM
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DATA
DATA COMM ENABLE LOGIC INSTRUMENT CLUSTER
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
EPS FUSE
HOT AT ALL TIMES
LT BLU WIRE
POWER STEERING MOTOR
RED/BLK WIRE
SENS SIG SENS RTN
SPLY VOLT
STEERING WHEEL ANGLE SENSOR (STEERING COLUMN)
TAN WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
WHT WIRE
