Chevrolet Equinox II (2009-2015) transmission body shift lever control position module indicator Wiring diagram
This page shows the only wiring diagram for the component.transmission body shift lever control position module indicator, which is found in the car Chevrolet Equinox II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission body shift lever control position module indicator (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR CONTROL MODULE
CENTER CONSOLE 1 ACCESSORY POWER RECEPTACLE
CENTER CONSOLE 2 ACCESSORY POWER RECEPTACLE
CENTER CONSOLE CUPHOLDER RIGHT ACCENT LAMP
DATA LINK CONNECTOR
FUEL ECONOMY MODE SWITCH
HORN SWITCH
HVAC CONTROL MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL DIMMER SWITCH
LEFT INSTRUMENT PANEL COURTESY LAMP
LEFT LOWER INSTRUMENT PANEL ACCENT LAMP
LEFT STEERING WHEEL CONTROLS SWITCH
NCA WIRE
NOT USED
PASSENGER AIR BAG INSIDE DISABLE REARVIEW INDICATOR MIRROR
PASSENGER PRESENCE DETECTION MODULE
POWER RECEPTACLE
RIGHT INSTRUMENT PANEL COURTESY LAMP
RIGHT STEERING WHEEL CONTROLS SWITCH
SEAT HEATING CONTROL MODULE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL ANGLE SENSOR
TRANSMISSION BODY SHIFT LEVER CONTROL POSITION MODULE INDICATOR
TRANSMISSION TRACTION SHIFT CONTROL LEVER SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ ACCESSORY STEERING WHEEL CONTROL
W/ MEMORY
W/ REARVIEW CAMERA
W/0 ACCESSORY STEERING WHEEL CONTROL
W/O REARVIEW CAMERA
W/O SPO W/ SPO HEATED HEATED SEATS SEATS
Go to component -> Ground distribution circuit (2 of 4) -> TRANSMISSION BODY SHIFT LEVER CONTROL POSITION MODULE INDICATOR
