Chevrolet Equinox II (2009-2015) steer whl lo ctrl stage 1 wiring diagram
This page shows the only wiring diagram for the component.steer whl lo ctrl stage 1, which is found in the car Chevrolet Equinox II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
steer whl lo ctrl stage 1 wiring diagram (1 of 1)
AIR BAG OFF IND
BATT POSITIVE VOLT
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA SERIAL
DK BLU WIRE
DK GRN WIRE
FRT PASS SEAT BELT IND CTRL
GMLAN LO SPD
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P BEC FUSE
I/P MOD HI CTRL STAGE 1
I/P MOD HI CTRL STAGE 2
I/P MOD LO CTRL STAGE 1
I/P MOD LO CTRL STAGE 2
IGN VOLT
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER CENTER CONSOLE)
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF DASH)
IOS MDL FUSE
LO SPD GMLAN SERIAL DATA
LO SPD GMLAN SERIAL DATA B+
LOGIC
MIR FUSE
NCA WIRE
ON IND AIR BAG
ORG/ WIRE
PASS AIR BAG OFF IND CTRL
PASS AIR BAG ON IND CTRL
PASSENGER AIR BAG DISABLE INDICATOR
PASSENGER INSTRUMENT PANEL AIR BAG (RIGHT SIDE OF DASH)
PASSENGER PRESENCE DETECTION MODULE (BELOW PASSENGER'S SEAT CUSHION)
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED/WHT WIRE
RIGHT FRONT IMPACT SENSOR (RIGHT SIDE OF RADIATOR SUPPORT)
RIGHT FRONT SIDE IMPACT SENSOR (PASSENGER DOOR)
SDM (BATT) FUSE
SDM IGN FUSE
SEAT BELT IND
SEAT BELT IND AIR BAG IND
SHORTING BAR
STEER WHL HI CTRL STAGE 1
STEER WHL HI CTRL STAGE 2
STEER WHL LO CTRL STAGE 1
STEER WHL LO CTRL STAGE 2
STEERING WHEEL AIR BAG (IN STEERING WHEEL)
STEERING WHEEL AIR BAG COIL (STEERING COLUMN)
TAN WIRE
TAN/ORG WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> STEER WHL LO CTRL STAGE 1
