Chevrolet Equinox II (2009-2015) rh roof rail mod high ctrl rh roof rail mod low ctrl Wiring diagram
This page shows the only wiring diagram for the component.rh roof rail mod high ctrl rh roof rail mod low ctrl, which is found in the car Chevrolet Equinox II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh roof rail mod high ctrl rh roof rail mod low ctrl (1 of 1)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER SEAT BELT RETRACTOR PRETENSIONER (BASE OF DRIVER "B" PILLAR)
DRIVER SEAT BELT SWITCH (INTEGRAL TO DRIVER SEAT BELT BUCKLE ASSEMBLY)
GRY WIRE
GRY/BLK WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER CENTER CONSOLE)
LH SEAT BELT SW LOW REF RH SEAT BELT SW LOW REF RH SEAT BELT SW SIG
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
PASSENGER SEAT BELT RETRACTOR PRETENSIONER (BASE OF PASSENGER "B" PILLAR)
PASSENGER SEAT BELT SWITCH (INTEGRAL TO PASSENGER SEAT BELT BUCKLE ASSEMBLY)
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RH ROOF RAIL MOD HIGH CTRL RH ROOF RAIL MOD LOW CTRL
RIGHT REAR SIDE IMPACT SENSOR (RIGHT REAR DOOR)
RIGHT ROOF RAIL AIR BAG (RIGHT ROOF RAIL)
SHORTING BAR
TAN/BLK WIRE
TAN/ORG WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> RH ROOF RAIL MOD HIGH CTRL RH ROOF RAIL MOD LOW CTRL
